4tons mobile lpg gas station with lpg gas dispenser and pump skid mounted lpg gas filling station

Price:	32110.0 USD
Payment Terms:	T/T,L/C
Place of Origin:	Hubei, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Means of Transport: Ocean,Land

Packing: waxed

Brand Name: CLW

Production Capacity: 20 units/month

Delivery Date: 45 days

Skid lpg gas station is also called lpg skid-mounted filling station LPG GAS dispenser, Mobile Skid LPG Gas Station,lpg mounted skid refilling station

Skid lpg gas station is also called lpg skid-mounted filling station LPG GAS dispenser, Mobile Skid LPG Gas Station,]lpg mounted skid refilling station, LPG FILLING SKID STATION, lpg filling station skid-mounted moving, lpg propane skid station, LPG skid station gas station, lpg skid-mounted filling station, LPG Skid-Mounted station with LPG tank, dispensers, valves, pumps and skid, etc.

Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of lpg gas pressure vessels, such as bulk lpg tank, lpg gas trailer, lpg gas truck, skid lpg gas filling plant, lpg gas bobtail vehicle, lpg gas dispensing truck, etc. And recently, our company lpg gas pressure vessesl products have passed ASME. That is to say, our lpg pressure vessels can be exported to USA, Europe, etc.

> LPG storage tank with capacity of 5cbm up to 120cbm
> Color : as per customer request
> Dispenser:one gun or two gun dispenser available
> LPG Filling pump with motor
> LPG discharging pump with motor
> LPG hose assembly and quick connector
> Safety Valve+Liquid Level Indication + Pressure Gauge + Thermometer etc
> Other valves and necessary accessories for the operation of lpg filling station

More pictures of hot sale 10cbm 4tons mobile skid mounted lpg gas filling plant for filling gas bottles as below .

‍

1,Spedification

10cbm MOBILE LPG Skid Station
Volume of Tank		10 CBM
Filling Weight		4000 kg
Tank Weight		3000 kg
Thickness of Shell (mm)		10 mm
Thickness of Endplate (mm)		10 mm
Tank Diameter (mm)		1600 mm
Tank Dimensions(inner diameterthicknesslength) (mm)		DN1600105940
Whole dimension (mm)		7260 x 1620 x 2510 mm
Material of Tank and Main Pressure Parts		Q345R,16MnIII
Filling Medium		Liquefied Petroleum Gas ( Propane)
Design Pressure		1.77 MPa, 17.7 Bar
Working temperature (℃)		≤50
Hydraulic test pressure (Mpa)		2.22
Air test pressure (Mpa)		1.77
Corrosion Allowance		1 mm
Medium Density		500-570 kg/ cbm
Manufacturing Standard: Pressure vessels, Supervision Regulation on Safety Technology for Stationary Pressure Vessels of China.
Filling accessories for MOBILE SKID LPG STATION
Item	Specification		Quantity
Hydrocarbon pump	YQB15-5		1
Anti-static motor	MM2JA160MBB		1
alarm	QJ-D-99F		2
Liquid meter	L=1800mm DN20		1
Safety valve	A42F-25 DN50		1
Safety reflux valve	AH42F-25 DN25		1
Check valve	H42N-40 DN50		2
Stop valve	J41N-40 DN50		25
	J41N-40 DN32		1
	J41N-40 DN25		4
	J41N-40 DN20		2
	J41N-40 DN20		10
Pipe safety valve	A21F-25 DN15		1
Discharge pipe	L=4M DN50/DN25		1
Shock tube	L=500MM DN50		2
Filling gun with pipe	L=2M		3
Elbow	DN65		2
	DN50		10
Flange	2.5mpa DN65		1
	2.5mpa DN50		50
	2.5mpa DN32		1
	2.5mpa DN25		8
	2.5mpa DN15		20
Electric filling scale	BSC-150		1
Metal pads	DN65		5
	DN50		80
	DN32		2
	DN25		10
	DN20		2
	DN15		30
bolt	16*70		300
	16*55		100
